Indoor Infrared Motion Surface Mounted Sensor

Mounting Type Surface mounted
Input Voltage 220-240V AC 50/60Hz
Detection Range 360°
Detection Distance Max. 20m (<24°C)
Detection Motion Speed 0.6-1.5m/s
Rated Load 2000W halogen/ 1000W CFL/ 1000W LED
Time Delay Min. 10s±3s; Max. 30m±2m (Restarts from last movement)
Ambient Light <3-2000lux (Adjustable)
Ambient Temp -20 to +40°C
Working Humidity <93%RH
Power Consumption approx 0.5W
Installation Height 2.2-6m
Housing Material PC
IP Rating IP20
Warranty 5 year manufacturer warranty



UV resistant
3 wire
Day/ Night recognition
Manual override
